project

Function

Equipment size

945mm*700mm*1850mm

Corresponding nozzle type

NXT H24,V12,H08

End face inspection

Template matching + end face measurement, 6-megapixel color area scan camera, achieving ultra-high precision detection

blocking detection

Flow sensor imported from Japan performs high-precision detection of blockage

Slip detection

0~500N, ±1 high-precision detection smoothness

QR code recognition

1.6 million global exposure camera, faster

Cleaning method

High pressure water column cleaning

Clean the nozzle

8 sets of opposing nozzles, 16 on each side

cleaning solvent

Compatible with distilled water, DI water

Single cleaning quantity of cleaning vehicles

H24: 84 pieces can be cleaned at one time, H12: 40 pieces can be cleaned at one time

Data logging function

Customers can choose whether to record cleaning and maintenance information, and automatically save the image information of the nozzle after maintenance, and correspond to the QR code one-to-one

Nozzle configuration library

Customers can add various types of nozzles themselves, with no arbitrary limit on the quantity

Number of nozzle holders installed

3, same principle as NXT

User permissions

Customers can edit by themselves and modify and add without restrictions
